产品名称 : 恒流SMD2835软灯条
产品型号 : CK-2835-60-DC24V-XX-10mm-IP20
质保 : 3年
认证: ETL, CE, ROHS
- 产品参数
- 特征
- 数据下载
|
Part NO. |
CK-2835-60-DC24V-XX-10mm-IP20 |
|
LED Type |
SMD2835 |
|
Lumen / LED |
20-24lm/LED |
|
LED Quantity /M |
60pcs |
|
Constant IC Quantity /M |
20pcs |
|
Working voltage |
DC 24V |
|
Wattage /M |
10W |
|
Standard Length |
Within 20meters |
|
PCB |
3 OZ |
|
PCB Width |
10mm |
|
Wire length |
200mm |
|
Beam angle |
120 ° |
|
Color Available |
3000K/4000K/6000K/10000K |
|
Working temperature |
-20~40 °C |
|
Storage temperature |
-25~60 °C |
|
IP rank |
IP20/IP54 |
|
Warranty |
3 years |
-
Using SMD2835, 20-24lm per LED, San’an chip. Perfect combination of advantages of SMD5050 and SMD3528 strips
-
Constant current design, very low voltage drop for 20 meters reel
-
Double layer 3OZ pcb, high efficiency
-
Single Bin to be used to guarantee CCT consistency
-
24V version 6 LEDs cuttable
-
OEM ODM available
-
50,000 hours durable lifespan
-
IP rank can be IP20, IP54
