产品名称 : RGB + CCT软灯条
产品型号 : CK-5050-60-DCXX-RGBW-12mm-IP20
质保 : 3年
认证: ETL, CE, ROHS
- 产品参数
- 特征
- 数据下载
|
Part NO. |
CK-5050-60-DCXX-RGBW-12mm-IP20 |
|
LED Type |
SMD5050 |
|
LED Chip |
San’an |
|
LED Quantity /M |
60pcs (30pcs RGB LED, 30pcs CCT dimmable LED) |
|
Working voltage |
DC 12V |
|
Wattage /M |
14.4W |
|
Standard Length |
5m |
|
Width |
12mm |
|
Wire length |
200mm |
|
Beam angle |
120 ° |
|
Color Available |
RGB + CCT dimmable 2700-6500K |
|
Working temperature |
-20~40 °C |
|
Storage temperature |
-25~60 °C |
|
IP rank |
IP20/IP54/IP65/IP67 |
|
Warranty |
2 years |
-
Using high brightness SMD5050, San’an chip
-
RGB and CCT dimmable
-
Double layer 2OZ pcb, high efficiency
-
12V version 6 LEDs cuttable
-
OEM ODM available
-
50,000 hours durable lifespan
-
IP rank can be IP20, IP54, IP65, IP67
